Video format

NTSC/EAI or PAL/CCIR

Hard disk storage

IDE type, UDMA 66, support 200GB HDD

Record mode

Manual/ Alarm/ Timer/ Motion

Camera Input Signal

Composite video signal 1 Vp-p75ΩBNC, 4 channels

Camera Loop Back

Composite video signal 1 Vp-p75ΩBNC, 4 channels

Main Monitor Output

Composite video signal 1 Vp-p75ΩBNC

Call Monitor Output

Composite video signal 1 Vp-p75ΩBNC

Audio Input

4 audio inputs, (RCA)

Audio Output

2 audio output, (RCA)

Motion Detect Area

15*12targets per camera (NTSC)/ 15*14 targets per camera

Motion Detect Sensitivity

256 levels

Video Loss Detection

Yes

Refresh Rate

Up to 120 images/sec. For NTSC / 100 images/sec. For PAL

Recording Rate

Up to 25 images/sec. For NTSC / 18 images/sec. For PAL

Dwell Time

Programmable (1~10 Sec)

Picture in Picture

Yes (Movable)

Key Lock

Yes

Picture Zoom

2*2 (Movable)

Camera Title

6 letters

Video Adjustable

Color/ Contrast/ Brightness Adjustable

Alarm Input

TTL input, Hi (5V), Low (GND)

Alarm Output

COM,/N.O

Remote Control

RS-232 or RS-485

Time Display Format

YY/MM/DD, DD/MM/YY, MM/DD/YY, OFF

Power Source

AC100~240 +/- 10% switching adaptor

Power Consumption

<32W

Operation Temperature

10~40^oC

RS-232C / RS-485 (bps)

115200,57600,19200,9600,4800,3600,2400,1200

Dimension (mm)

430(W) x 300(H) x 65(D)

Net Weight

5.4kg
