Video format

NTSC/EAI or PAL/CCIR

Hard disk storage

IDE type, UDMA 66 above, support 200GB HDD

Record mode

Manual/ Alarm/ Timer/ External

Playback searching

Date& Time/ Alarm searching

RS-232

Yes

Video Input

1 video input, composite 1 Vp-p/ 75ohm (BNC)

Video Output

1 video output, composite signal 1 Vp-p75ΩBNC

Video resolution

720x486(NTSC), 720x576(PAL)

Video compression

Wavelet

Audio input

Yes

Audio output

Yes

Video Loss Detection

Yes

Refresh Rate

60 images/sec. For NTSC / 50 images/sec. For PAL

Recording Rate

60 images/sec. For NTSC / 50 images/sec. For PAL

Key Lock

Yes

Alarm Input

TTL input, Hi (5V), Low (GND)

Alarm Output

COM,/N.O/ N.C

Time Display Format

YY/MM/DD, DD/MM/YY, MM/DD/YY, OFF

Power Source

AC90~240 +/- 10% switching adaptor

Power Consumption

<27W

Operation Temperature

10~40^oC

On Screen Display

Yes

Dimension (mm)

380mm(W) x 270mm(H) x 65mm(D)

Net Weight

5.4kg
